LC2002 Digital Power Amplifiers
|
Main Features - Small size,
lightweight 2 channels amplifier
|
|
|
|
 |
|
Technical Specifications |
| Parameter | PKN LC2002 |
|---|---|
| Channel number | 2 input / 2 output |
| Power requirements |
160V - 270VAC, 50-60 Hz |
| Max. Power consuption |
6 A |
| Soft starting |
yes |
| Power Supply |
High frequency resonant includes active PFC |
| Mains connection |
Neutrik Powercon |
| Working temperature range |
0C - 40C |
| Storage temperature range |
-25C - 60C |
| Output power @ 8 Ohms |
2 x 500W |
| Output power @ 4 Ohms |
2 x 1000W |
| Output power @ 2 Ohms |
2 x 1600W |
| Minimal load impedance |
2 Ohms |
| Frequency (+/- 3dB, 8 Ohms) |
5 Hz - 22 kHz |
| Slew rate |
50V / us |
| Damping factor |
>400 |
| End stages |
Single ended Class D |
| Output connection |
Four pole Neutrik Speakon (1+2+ in parallel 1-2- parallel) |
| Signal to noise ratio |
104 dB |
| Nominal sensitivity for max. output level (balanced) |
700 mV (rms) |
| Input impedance (referred to ground) |
10 kOhms + 10 KOhms ( +/- 1% ) |
| Input terminals |
Neutrik XLR |
| Built in limiter |
yes |
| Crossover |
selectable 100 Hz HI-PASS filter, 120 Hz LO-PASS filter, 160
Hz LO-PASS filter |
| Output level meters |
SIGNAL, AGR, PROTECTION, TEMP, READY LEDs |
| Protections |
Short circuit, Overload, Low impedance, thermal, DC fault |
| Cooling |
Forced air cooling with regulated DC fans |
| Direction of air flow |
Front to rear |
| Bridged configuration ability |
yes |
| Remote |
- |
| Weight |
6 Kgs |
| External dimensions |
19" rack 483 x 460 x 44mm (1RU) |
|
*MSRP (Please contact PKN Audio for
special price) one unit per export paper box |
|
|
